10 examples of resistors in circuits

September 16, 2023
written by Qamar Zaman

A resistor is a passive two-terminal electrical component that implements electrical resistance as a circuit element. Resistors are fundamental components in electronic circuits, and they serve various purposes in controlling current and voltage.

Examples of Resistors in Circuits

Here are 10 examples of resistors.

image of Examples of Resistors in Circuits

1. Voltage Divider

A voltage divider circuit uses two resistors in series to divide a voltage source into a lower voltage. This is commonly used in applications like setting reference voltages or biasing transistors.

2. Current Limiting Resistor

To prevent excessive current flow through an LED or any diode, a current-limiting resistor is placed in series with the device. It ensures the LED operates within its safe current range.

3. Pull-up and Pull-Down Resistors

In digital circuits, pull-up and pull-down resistors are used to ensure that a signal line remains at a defined voltage level when no active driver is connected.

4. Voltage Divider Biasing (Bias Resistor)

In transistor amplifier circuits, biasing resistors set the operating point of the transistor. They help establish the desired DC voltage levels at the transistor’s terminals.

5. Filter Networks

In passive filter circuits like low-pass, high-pass, and band-pass filters, resistors are used to determine the filter’s cutoff frequency and response.

6. Current Sensing Resistor

Current sensing resistors are placed in series with a load to measure current. They convert current into a voltage drop that can be easily measured.

7. Voltage-to-Current Conversion

A resistor can convert a voltage signal into a proportional current signal, useful in applications like current loops and transmitters.

8. Termination Resistor

In high-speed digital circuits, termination resistors (e.g., pull-up or pull-down) are used to match the impedance of the transmission line and reduce signal reflections.

9. Adjustable Voltage Regulators

In adjustable voltage regulator circuits, a resistor divider network helps set the output voltage to the desired level.

10. Heater Elements

Resistors are used as heating elements in applications such as electric stoves, toasters, and space heaters, where electrical energy is converted into heat.

These examples demonstrate the versatility and importance of resistors in various electronic circuits. They play a crucial role in controlling current, voltage levels, and the behavior of electronic devices
